Lampe de chauffage infrarouge industrielle à ondes moyennes peinte en blanc
Les radiateurs infrarouges industriels présentent les avantages de hautes performances, de fiabilité, de longue durée de vie (plus de 10 000 heures), d'un rayonnement infrarouge stable et doux, d'une installation facile et d'un faible coût.
Tension d'entrée : 220 V
Puissance d'entrée : 800 W
Durée de vie utile : plus de 5 000 heures
Distance infrarouge : 2-4 μm.
OEM/ODM : peut être personnalisé selon les exigences du client.
- REMA
- Chine
- 5 à 10 jours
- 200000 pièces
- information
REMA 220v 800w White-painted Infrared Heaters Lamp Quartz For Drying Textiles.
The top quality of filament can let the lamp keep long time life
1.High efficiency.
2.Economical to run.
3.Have a fast response switching on and off timeEffectively transmit and focus heat on materials
High purity99.99% qurtz glass tube
1.Is totally transparent at lR radiation.
2.quartz is used in halogen bulbs because it can withstand high temperatures. Quartz alsoensures against heat shock.
Name： | White Medium Wave Infrared lamp | Voltage ： | 24-600V |
Wattage | 100-5000W | Heated length ： | 100-6000mm |
Response time： | 1-2min | Wavelength： | 2-4 um |
Tube diameter： | 8-20mm | Filament temperature： | 1100-2900℃ |
Application：Automotive manufacturing, textiles, plastics, spraying, paper making, printing, inks, adhesives, solar photovoltaics, etc | |||
Quartz infrared heaters are used in various industrial applications：
Drying process in paper mill
Fusing printing ink
Pre-heating before embossing
Glass Curing
Preheating and curing wood coating
Shrink Packaging Machines.
Lacquers drying
Processing Plastic foils and sheet
Halogen heaters with reflective film
A white coating is applied to the rear surface of the lamp which increases the efficiency and the energy
emitted from the front of the lamp, and eliminates the optical components, such as the reflective mirror,
reducing the cost. It also helps suppress the increase in temperature of surfaces on the side of the reflective
OEM/ODM
If the parameter is not suitable for you. Welcome to contact us .REMA Design an infrared lamp for the unique you ！
| How to customized ? Pls provide this informations: | |||
| 1.Voltage: | 220V、380V、... | 2.Wattage: | 1000w、2000w、.. |
| 3.Total length: | **mm | 4.Wire length: | 500MM、..... |
| 5.Coated or not.What color coating？ | Gold/ White/ Clear/Black | 6.Base： | SK15、R7s、..... |
| Or you can directly send us the photos and drawings. | |||
Custom Lamp Base LOGO
REMA uses laser printing LOGO. Make the LOGO more clear , durable and not easy to disappear by friction.
AFTER-SALE GUARANTEE
Maintenance and care:
– Regular cleaning: During use, dust, oil and other impurities may accumulate on the surface of quartz heating lamp, affecting its heating effect and service life. Therefore, it is necessary to clean the quartz heating lamp regularly, and you can use a clean soft cloth or paper towel to gently wipe the surface.
– Check the circuit: Regularly check whether the connection circuit of the quartz heating lamp is normal, whether there is looseness, short circuit, etc., to ensure its normal operation.
– Avoid collision: Quartz glass is relatively fragile. Avoid collision or falling during installation and use to avoid damage to the quartz heating lamp.
